DOSIMETRIX®hybrid
10 – 40 % less concentrate consumption
Fully automatic dosing. Always the right concentration and fill level.
What makes DOSIMETRIX® hybrid special
Factor 2–3 longer coolant service life
A stable, precisely controlled emulsion significantly extends service life — less remixing, less disposal, lower costs.
SmartFusion finely dispersed emulsion
Droplet size < 0,5 μm — an emulsion quality that most competitors do not achieve. Longer service life and better compatibility.
Contactless NFC measurement
The readings are transferred automatically via NFC from the Atago PAL1 to the app and the eMix1500 — no manual transfer, no misreadings.
Stronger together — Brisco and ATAGO
Brisco Systems GmbH
Hersteller DOSIMETRIX® hybrid
ATAGO CO., LTD.
Manufacturer partner · Refractometers
6 Parameters.
Fully Recorded.
DOSIMETRIX® hybrid captures all critical coolant parameters — digital, precise and fully documented in the FLUIDAS Analysis Portal.
Concentration %
Precise to ±0.1 % — reduce coolant consumption and tool wear
Fill Level L
Tank fill level continuously monitored — never run dry again
pH Value pH
Detect bacterial growth and corrosion early
Conductivity mS/cm
Monitor water quality and oil degradation
Temperature °C
Control cooling performance and thermal load
Water Hardness °dH
Keep scale deposits and emulsion stability in check
Automatic dosing.
Precise mixing.
- Up to 100 individual tanks*individually controlled
- SmartFusion mixing technologyDroplet size < 0.5 μm for significantly longer coolant service life
- Controls concentration and fill levelfully automatic, for stable emulsions
- 0 – 15 % seamless concentration controlfor all common coolants
- Coolant manufacturer neutralfor maximum investment protection
- Volume detectionsafe and redundant overfill protection
* depending on pipe length
FLUIDAS Analytics Portal closes the loop.
The core element is the DOSIMETRIX® hybrid eMix1500 — it doses and mixes fully automatically. FLUIDAS is the software for it: it transfers the readings, shows all tanks in real time, alerts automatically and documents TRGS-611-compliant — on desktop, tablet and smartphone.
- Real-time dashboardall coolant parameters of all tanks at a glance
- Automatic alertsby email when limit values are exceeded
- Trend analysis & historyconcentration history per tank, unlimited time period
- TRGS 611 compliant documentationcomplete logs for compliance & audit
- Individual limits per tanksetpoint, min/max, tolerance band freely configurable
- Coolant consumption analysismake cost transparency and savings potential visible
- Web, iOS & Android App, Tabletavailable on all devices, also usable offline
Support & On-site Installation
Turnkey systems: Depending on customer requirements, we offer systems with piping or hosing and connection to other equipment — such as return lines from chip presses. We take full responsibility for the complete installation.
Support by Region
In Germany and BENELUX, GIMAT GmbH as system integrator is your first point of contact for planning, integration and support. In all other countries, please contact your local partner or Brisco Systems directly. You are welcome to use the Google Remote Desktop Tool to communicate with us easily.
On-site & Partners
On-site appointments are carried out by GIMAT (DE/BENELUX), local partners or directly by Brisco Systems. Remote maintenance and monitoring are available throughout Europe. Installation and commissioning by Brisco Systems itself.
- DE & BENELUX: GIMAT GmbH — gimat.de
- UK: Lubriserv — lubriserv.com
- Spain: Crosstools — crosstools.es
- Hungary: MotulTech — motultech.hu
- Italy: Tecnimetal — tecnimetal-tm.com
- All other countries: Brisco Systems directly
Ready for Automatic Coolant Management?
Speak with our experts now. Free initial consultation, non-binding.
Free · Non-binding · Reply within 24 h
